xTool S1 Enclosed Diode Laser Cutter

Key Features & Benefits

1. Switchable laser modules satisfy the processing of almost any material.
2. Pin-point™ positioning: 10 times more accurate than single-camera systems.
3. Larger bed size than others: 23.93” x 15.16” for efficient batch processing.
4. AutoPassthrough™ and 3D Curve™ Engraving.
5. Class 1 Safety: 5-direction flame detection, emergency stop, lid-open safety stop and laser key lock.

Powerful Diode Laser Options
Available in 10W, 20W, and 40W modules, with an optional 1064 nm IR laser kit for advanced woodworking and engraving. Capable of precise cutting and engraving across wood, leather, acrylic, paper, fabric, and more.

Generous Work Area
Supports projects up to 498 × 319 mm, giving you the flexibility to create large or multiple items at once.
Optional conveyor feeder extends the work area for small-batch production.

Fast, Accurate Motion
High-speed gantry system ensures smooth curves, detailed engravings, and precise cuts, even at maximum speeds.

Smart Features for Makers

Live Camera Preview
Monitor your project remotely and create timelapse videos for sharing or quality checks.

xTool Studio Software
Intuitive interface, AI-powered tools, and preset parameters make design and workflow simple for beginners and pros alike. Compatible with popular vector and raster files for maximum flexibility.

Modular Laser Heads
Swap between diode and IR modules in seconds to expand material compatibility and capabilities.

Materials You Can Work With

Engrave: Wood, leather, MDF, cork, acrylic, fabric, paper, felt.
Engrave Only: Glass, metal* (with IR module), stone, ceramics.
